10.4inch Integrated Industrial Touch Panel PC

With powerful processors, ample memory and storage, and a wide range of connectivity options, Industrial Touch Tablet PCs are equipped to handle complex applications like inventory management, equipment diagnostics, and remote monitoring. They can operate in various conditions, whether in a factory setting, on a construction site, or out in the field, ensuring that workers have the tools they need at their fingertips.

LCD Panel: 10.4’’ TFT-LCD

Resolution: 1024x7684

Brightness: 300cd/㎡-450 cd/㎡

Viewing Angle: 70/70/60/70

Light transmittance: ≥85％

Processor: Optional Celeron j1900 or Core i3i5i7 3/4/5/6/7/8/9 generation CPU

Display: LCD+HDMI dual display, synchronous or asynchronous display

Hard disk: 1 x SATA port,1 x mSATA slot

I/O:
1*VGA interface (built-in pin),1*HDMI1.2 interface,1*LVDS interface (default LVDS, optional eDP interface)

2*8821H Gigabit network adapter (optional), supporting network wake up /PXE

4*USB interface (default), expandable up to 9*USB

2* DB9 RS232 Serial port (default)

1* Mini-PCIe slot (long card), supporting WIFI/4G module

1* Mini-PCIe slot (half card), supporting WIFI module

1* Onboard ALC897 7.1 channel high fidelity audio controller, support MIC/Line-out, power amplifier (2 euro 5W dual channel)

1 x 12V DC power input port (default power supply). DC 12V ±5% power supply is used. 9 to 36V wide voltage module is optional

1* external TPM2.0 pin interface 2*7pin (default is not attached)

1*4pin CPU fan interface, 1*4pin system fan interface

1 x JVGA port 1 x 12 pin

1* hard disk power port

1* power amplifier interface 1*4pin

BIOS, 64Mb Flash ROM

Operation system: Windows 7, Windows 10, Linux, and xp

Dimension: 276.6×221.6×56.5mm

Weight: 2.80KG
