Intel® Core Series i3/i5/i7 6th/7th Generation
Operation System: Support Win7/Win8/Win10/Linux
1*SATA 3.0, 1*M.2 (NVMe protocol)
1*EDP,1*HDMI,1*VGA(Support dual screen synchronization)
4*USB3.0, 4*USB2.0 (2 USB2.0 pins)
1*DDR3 notebook memory slot supports up to 8GB
2*RTL8111H Gigabit card
1*WiFi or 1*4G module
1*SATA 3.0, 1*M.2 (NVMe protocol)
1*EDP,1*HDMI,1*VGA(Support dual screen synchronization)
4*USB3.0, 4*USB2.0 (2 USB2.0 pins)
1*DDR3 notebook memory slot supports up to 8GB
2*RTL8111H Gigabit card
1*WiFi or 1*4G module
Processor: Intel Sky Lake-U Kaby Lake-U corei3/i5/i7 6th/7th Generation
Memory: 1 x DDR3L-1600MHz, SO-DIMM slot 1.35V supports a maximum of 8GB
Hard Disk: 1*SATA 3.0，1*M.2(Key-M, 2280, PCIe x2 NVMe/ SATA, SSD)
Operation system: Windows7/Windows 10/Linux
Display: 1 x VGA port; 1*HDMI port; 1*EDP (Support VGA+HDMI+EDP dual screen synchronous display)
Wifi: support Wifi or 4G module
Network Card: 2*Realtek PCI-E bus RTL8106E/RTL8111H Gigabit NIC chip
Audio: RealtekALC897 7.1 channel HDA encoder with MIC/ line out port support
BIOS: AMI UEFI BIOS
Power Supply: DC12V
Fan interface: Backmounted CPU fanless heat dissipation design
Working humidity: 5%-95% relative humidity, no condensation
Operating temperature: 60℃~-20℃
