Intel® Core Series i3/i5/i7 8th/9th/10th Generation
1*SATA, 1*M.2 (NVMe protocol)
1*HDMI,1*VGA(support synchronous asynchronous display)
4 x USB3.0, 2 x USB2.0
1*DDR4 notebook memory slot supports up to 32GB
1 x Intel 2.5G NIC, 1 x Intel i219 NIC
1*4G module
Processor: Intel Sky Lake-U Kaby Lake-U corei3/i5/i7 8th/9th/10th Generation
Memory: 1* DDR4 2666/2933MHz memory slot, the entire board supports a maximum of 32GB
Hard Disk: 1*SATA3.0, 1* M.2(NVME, SATA/PCIE HDD supported)
Operation system: Windows7/Windows 10/Linux
Display: 1*HDMI (DP optional) +1*VGA, supporting synchronous or asynchronous display
Extension interface: 1* full-length MINI-PCI-E(USB 3G/4G communication module)
Wifi: support Wifi or 4G module
Network Card: 1 x Intel i225 2.5G+1 x Intel i219V Gigabit network ports, supporting network wake up. PXE function
Audio: RealtekALC897 7.1 channel HDA encoder with MIC/ line out port support
BIOS: AMI UEFI BIOS
Power Supply: DC12V
Fan interface: Backmounted CPU fanless heat dissipation design
Working humidity: 5%-95% relative humidity, no condensation
Operating temperature: 60℃~-20℃
